Echo Click Smart zigbee Switch Socket Insert DIY Part Customized Free Combinations Black Color
DISCOUNT CODE
Features
Spec
Product Introduction
Certificate
Manual & More
Simple Operation And Easy Installation
Product Installation Video Tutorial
Downlods
Packing List
How to choose?
ZIGBEE switch socket free combine multi-control 2 way light switch eu wall electric socket
Features:
Multi-Control Association: wifi switches have 1/2/3/4way and can control one light from four Different places(the maximum is 4 way). If you want to control 1 light from 3 places you need to buy 3 pieces of wifi switches.4. Different quality testing during production, to ensures each switch works well before it is delivered to customers.5. Elegant look, Suited greatly with many modern decor styles. It can be applied to drawing rooms, bedrooms, corridors, kitchens, bathrooms, Office, ect.
App Installation:
Download The Tuya or Smart Life App To Your Smartphone or Tablet. The App Can Be Downloaded From Apple App Store or Google Play, Then Connect Your App With Amazon Alexa Or Google Home Which Enable You To Voice Control Your Lights And Appliances.
Multi-function: remote control, timer, turn off backlight, power failure memory, rename, multi-control association, share device authority, connect voice
Product Introduction:
| Max. Strom: 10A | Load: 1000W/Gang |
| Wireless consumption: ≤0.2W | Max. Spannung: 110~ 240V(AC) 50/60Hz |
| Relative Humidity: 10% ~ 95% | Working Temperature: -20 ℃~+70℃ |
| Certification: CE, RoHS,EAC | WiFi Frequency: IEEE802.11 b/g/n |
| WIFI Standard: Wifi 2.4G | APP: Tuya/Smart Life |
| Voice Control: Google Home, Amazon Alexa | Wire: Need Neutral Wire |
| Back Light: ON-light Yellow OFF-Weak white | Moduel shape: Round |
| Wall Box Type: Round & Square |
Note: You have to cut off the power and during the installation.
Packaging:
Packing box *1
Function key *1
Panel *1
Screws *2
FAQ:
Q: What if my WiFi switch can't connect to the network?
A: 1. Please check your WiFi signal, our switch supports 2.4G Hz signal network.
2.Please check your router capacity, home general WiFi network generally support 10-15 WiFi devices, high-end router netware can accommodate more than 15 devices.
Q: What should I do if my switch is blinking?
A: Please check your bulb power, bulb under 7W may flicker, please choose bulb above 7W.
Q: How does WiFi enter pairing mode?
A: Please press and hold the switch until the yellow light blinks rapidly.
Q: How to reset the WiFi switch?
A: Please delete the switch in APP then long press to reconnect.
Q: What should I do if my WiFi switch always drops out?
A: Please delete the switch, disconnect the power and re-match. If it is still offline please test it with a cellular hotspot.
Q: What if my WiFi switch doesn't work?
A: Will make sure you connect the light cord. Use a power pen to test if it is energized. Check if the neutral and fire wires are connected correctly.
Q: What if my WiFi switch can't set 2Way?
A: Please connect the switch to the APP first, then set up the multi-control association
A: Yes, Our dimmer switch currently can do 2-way dimmer switch, but you need to buy at least 2 pieces（TW-GL86ZTD11,TW-GL86TDI11,GL86TD12）
Q: Do you have switches for multi-point control?
A: Yes, our smart light switch supports multi-control association.(Both WiFi and Zigbee series）
Q: Can your dimmer switch form 2-way with a light switch?
A: No. The dimmer switch can only be connected with the Dimmer switch, and cannot form 2-way with other switches
Q: Can your smart switch use voice control?
A: Yes. All of our smart switches can be controlled by voice through Alexa, Google Assistant, and some switches support Tmall Genie, Xiaodu, Yandex
Q: What should I do if the switch does not work after installing the upper panel?
A: Please do not turn on the power when installing the panel. You can try to disconnect the power and wait for 30 seconds before restarting. Please check the orientation of the iron plate, the side with the letters CE and RoHS is the backside
Q: What should I do if the blue light is not on when the product is installed?
A: Please use the electric test pen to check whether the wiring is electrified
Q: Does your smart touch sensor light switch need a neutral wire to install?
A:We have a different versions, with/without the neutral line version, support multiple wiring methods
Q: Can your smart touch light switch work with Home Kit?
A: Sorry, Our item can’t work with them now.
Q: Can your smart light switch work with Smart Life Tuya or Google Alexa?
A: Yes, it can work with them.
Q: Do you offer a 2-way wifi touch light switch?
A: Yes, we offer a 2-way wifi touch switch, it functions stably.But you must at least buy 2 pieces 2-way wifi switches. ( APP use multi-control association function)
Q: Does your switch have a backlight?
A: The blue backlight will be on when the wiring is successful. Allowing you to notice Our touch switch clearly in the dark.
Q: Does our switches can install by vertical or Horizontal for 157mm/228mm glass panel？
A: Yes, we can install it in different ways,
Q: Do you offer 2-way touch light switch?
A: Yes, we offer 2-way touch switch, it functions stably. But you must at least buy 2 pieces 2-way Touch switches.
Q: What does 2way mean?
A: 2way means you can turn on/off the same light from different places.
