BSEED Smart Thermostat Matter WiFi Temperature Controller Water/ Electric /Gas /Boiler Floor Heating With knob
DISCOUNT CODE
DISCOUNT CODE
10%
OFF
Order over €299
ORDIN10
COPY
COPIED
15%
OFF
Order over €499
ORDIN15
COPY
COPIED
18%
OFF
Order over €999
ORDIN18
COPY
COPIED
Color:White
Type:Electric
Features
Spec
Product Introduction:
Brand Name:
BSEED
current:
50/60Hz
Max. Strom:
5A(water heating/ wall furnace/ boiler) 16A (electric heating)
Max. Spannung:
90-240V (AC)
Sensor:
NTC 3950,10K
Temperature Error:
±1℃
Time Error:
<1%
Temperature Control Range:
5 ~ 35°C
Room Temperature Range:
5 ~ 99°C
Storage Temp.:
-10~ 45°C
Working Temperature:
0 ~ 45°C
Screen:
LED Negative Display Screen
Key type:
Capacitive Touch Key
Wireless Consumption:
≤0.5W
Waterproof Level:
IP20
Relative Humidity:
5%~93%
Materal:
PC+ABS Engineering Plastics(flame retardant)
WiFi Frequency:
IEEE802.11 b/g/n
WIFI Standard:
Wifi 2.4G Hzb/g/n
APP:
Tuya / Smart Life
Voice Control:
Google Home, Amazon Alexa
Energy Monitoring:
Support
Warranty:
1 year
Certification:
CE, RoHS
Module Shape:
Square
Wall Box Type:
Round & Square
Wall Box Depth::
≥30mm
Wall Box Diameter::
≥60mm
Certificate
Manual & More
Simple Operation And Easy Installation
Step1 Accurately connect the power cable to the power terminal box.
Step2 Fix the mounting plate on the cassette with a screwdriver through two screws.
Step3 Hang the control panel onto the mounting plate.
Step4 Installation completed.
Product Installation Video Tutorial
Downlods
Packing List
Product * 1
Screw Spike * 2
User Manual * 1
Package * 1
Same series recommendation
€25.39
€25.44
€32.34
€34.30
€21.11
€19.00
€20.11
€24.81
€20.84
€21.30
SHOW MORE
SHOW MORE
How to choose?
How to install a floor thermostat:
Connect the wires correctly according to the instructions.
How to distinguish the types of floor heaters:
Underfloor heating systems are categorized into electric, water-based, and boiler-based systems. The primary way to differentiate them is by examining the heating device installed under the floor. Electric heating systems are suitable for underfloor installations such as heating cables, heating films, heating tiles, and thermal mural systems. Water-based systems are used to connect to NC/NO type actuator systems. Boiler-based systems are used to control the boiler heaters.
What are the differences between different heating systems:
Electric heating heats up and dissipates heat quickly, making it suitable for small areas and localized heating. Installation is simple and maintenance is convenient.
Do you need more help?
HELP CENTER
Overview
FAQ
Reviews
FAQs
Does it support temperature control for both heating and cooling?
Not supported. Standard thermostats only support heating; they do not support cooling. If you require a thermostat with cooling functionality, please purchase the 'W-BHT-006-GAW-FL' model, the Wi-Fi version.
What type of thermostat should I buy?
Thermostats typically support boilers, underfloor heating and electric heating. With electric heating, heating cables are usually laid under the floor, and an additional sensor is required. With underfloor heating, water pipes are usually laid under the floor, and the space is heated via a water circulation system. If you are unsure which type you have, please send your thermostat wiring diagram to our customer service team so they can help you confirm this.
Can an underfloor heating thermostat be used to control an air conditioner?
No. The underfloor heating thermostat can only be used to control underfloor heating. If you require an air conditioning thermostat, please purchase the dedicated model ‘W-BAC-3000’.
Do your products comply with EU standards?
Yes. Our thermostat products carry CE and RoHS certification, as well as test reports.
