BSEED Touch Screen rotary button Electric Floor Heating Water Boiler Room Thermostat WIFI Alexa Google App Temperature Controller BacklightFeatures:
1. 1.32 inch circular and 240*240 TFT shows your artistic taste.
2. Superfine aluminum side knob lets your fingers feel delicate.
3. Above 6H tempered glass keeps your screen away fromscratches.
4. Agile push button gives you an excellent experience.
5. Seven colors ambient light increase color to your life.
6. Variety brushed back panel options are suitable for differenthome styles.Product Introduction:
Power Supply:95 ~240 VAC, 50~60Hz
Please check the information laser printed on the back of the thermostat
CurentLoad: 5A (water heating gas boiler) 16A (electric heating)Sensor: NTC3950, 10K
Set Temp. Range: 5-35°c
Display Temp. Range:5 -99°c
Ambient Humidity. 5 -95 % RH(Non Condensing)
Storage Temp.:-10~ 45°C
Power Consumption: <1.5W
Shell Material:PC+ABS ( Fireproof)
Installation Box;86* 86mim Square or European 60mm Round Box
Wire Terminals: Wire 2 x 1.5 mm2 or1 x 2.5 mm2
protection Clas s: IP20
Buttons:Capacitive Touch Buttons
ln the box you will find
User Guide 1pc
wall plate 1pc
QC Passed 1pc
BEFORE WIRING AND INSTALLING
1.Read these instructions carefully. Failure to follow them could damagethe product or cause a hazardous condition.
2.Check the rathings given in the instructions and on the product tomake sure the product is suitable for your application.
3.lnstaller must be a trained, experienced service technician.
4.After installation is complete, check out product operation as providedin these instructions.MODEL DEFINITION
GA: Water heating,5A
GB: Electric floor Heating, 16A
GC: Water/Gas Boiler,5A
N: Modbus Communication
S2: Both internal sensor and floor external sensor
For example: BHT-700OGA
Voltage hazard, which may cause harm to human body and equipment. Be sure to cut off the power before installation!
